一、Main Configuration:

1. Fanuc or Siemens control system

2. Custom-designed jigs and fixtures

3. High-precision imported ball screws

4. Automatic loading and unloading assembly

5. Grinding head spindle with imported electric spindle

6. Diamond wheel dressing, automatic wheel truing

7. Both cooling oil and electric spindle have temperature control systems.

8. Grinding with oil-based coolant

9. Automatic loading and unloading can be added based on the product (pneumatic components use SMC)

二、Processing Accuracy:

1. Roundness: 0.0005mm

2. Angular dispersion: 10'

3. Surface roughness: 0.1um

4. Thread gauge size between 57.5°--60° thread intersection

   Diameter size accuracy within 0.04mm

三、Market Application

Used in industries such as fuel pump nozzles.
